High Quality Glass Bottle Filling Machine IV Solution Aseptic Filling Line
Brief introduction
Description
Customer Case
Featured Products
Glass Bottle IV Solution Liquid Filling Production Line
Brief Introduction:
Glass bottle IV solution production line is mainly used for IV solution glass bottle of 50ml~500ml cleaning, filling, stoppering, capping etc. It can be used for the production of glucose, antibiotic, amino acid, fat emulsion, nutrient solution and biological agents and other liquids etc.
Main Features:
1. Bottle washing machine adopts new design, rough cleaning adopts the same direction for bottle input and output, saving operators and machine space.
2. Bottle output from rough and fine washing machine adopts twice bottle receiving, avoiding bottle reversal and broken.
3. Bottle washing machine uses intermittent rinsing, avoiding cross contamination caused by continuous rinsing.
4. Bottle input adopts the combination of bottle hook and guide plate, making the bottle input reliable and no bottle reversal.
5. Washing water can be recycled and filtered, reduce water consumption.
6. Filling adopts time and constant current control principle;; filling quantity can be adjusted by computer with high accuracy.
7. No bottle no filling, can realize CIP/SIP.
Specification
Brief Introduction:
Glass bottle IV solution production line is mainly used for IV solution glass bottle of 50ml~500ml cleaning, filling, stoppering, capping etc. It can be used for the production of glucose, antibiotic, amino acid, fat emulsion, nutrient solution and biological agents and other liquids etc.
Main Features:
1. Bottle washing machine adopts new design, rough cleaning adopts the same direction for bottle input and output, saving operators and machine space.
2. Bottle output from rough and fine washing machine adopts twice bottle receiving, avoiding bottle reversal and broken.
3. Bottle washing machine uses intermittent rinsing, avoiding cross contamination caused by continuous rinsing.
4. Bottle input adopts the combination of bottle hook and guide plate, making the bottle input reliable and no bottle reversal.
5. Washing water can be recycled and filtered, reduce water consumption.
6. Filling adopts time and constant current control principle;; filling quantity can be adjusted by computer with high accuracy.
7. No bottle no filling, can realize CIP/SIP.
Specification
| Item | value |
| Production Capacity | 80-600 bottles/min |
| Condition | New |
| Automatic Grade | Automatic |
| Driven Type | Electric |
| Voltage | 220V/380V |
| Dimension(L*W*H) | 17800*6000*2300--24000*7000*2300 |
| Weight (KG) | 330 |
| Certification | CE GMP ISO |
| Warranty | 1 Year |
| Key Selling Points | High Safety Level |
| Marketing Type | New Product 2020 |
| Type | IV solution filling machine |
| Packaging Type | Cartons, case |
| Machinery Capacity | 4800-36000BPH |
| Automatic Grade | Automatic |
| Filling Material | Liquid |
| Packaging Material | Wood |
| Power | 64KW |
| Suitable bottle | Ampoule bottle |
| Material | 304/316L Stainless Steel |
