RG0.8-110C Automatic Soft Gelatin Encapsulation Machine (Water Cooling Type)

Brief introduction
INQUIRY
Description Customer Case Featured Products

Main features of the equipment:
1. It adopts large-size touch screen and has fault diagnosis function, which can store various operating parameters and reserve network interface.

2. The mold adopts aviation aluminum alloy and has a long service life. Optimized design, the number of cavities is large, and the mesh adhesive rate is low.

3, rubber drum, rubber smearing system and mold parallel design, high stability. It adopts independent motor variable frequency drive, full bearing design, high assembly precision, convenient adjustment, low noise and stable operation.

4, the rubber is micro-lubricated, truly no-clean, improve efficiency and save money.

5, rubber cooling using a separate split professional chiller, low energy consumption, high cooling efficiency.

6, the lower pill uses the net bucket, and there is a cold wind pre-determined type, so that the plastic pill molding is more beautiful, and the transportation is more reasonable.

7. The material bucket is adjustable in temperature, stirrable and with speed regulation, and is more suitable for suppressing Chinese medicine suspension.

8, small footprint, full-featured, very suitable for small and pilot test in the laboratory, but also small batch production.

Technical Parameters:

Roller die rated speed
0-7r/min
Roller die size
φ72×110 mm
Single piston feeding volume
0-0.8ml
Power supply
380V 50Hz
Noise
<75 dBA
Dimensions
1500×550×1700 mm
Net weight
700kg
Total power
6.6 KW
